EWH2GM221M45OT

EWH2GM221M45OT
Description

Created
Last updated by adrian95
2 Contributor(s)
jharwinbarrozo
adrian95

Controls

Properties

Manufacturer Name
AISHI(艾华集团)
Designator Prefix
C
Manufacturer Part Number
EWH2GM221M45OT
Package or Case Code
CAP-TH_BD18.0-P7.50-D1.2-FD
Part Type
Aluminum Electrolytic Capacitors - Leaded
JLCPCB Part Class
Extended Part
Capacitance
220u F

Availability & Pricing

DPNStockQty 1
1974$1.4947
