Building Raspberry Pi Modem

Thought

flux

Work done

Updated project description to “Raspberry Pi Gateway Board Featuring Ethernet, ESP32, and Wi-Fi HaLow Support”
Defined system architecture in project property with mermaid diagram
Added 3.3 V LDO regulator U4
Added decoupling capacitors C1, C2, C3 and pull-up resistor on LDO EN
Added Raspberry Pi 40-pin header J1 and RJ45 MagJack with onboard magnetics J2
Created 5 V net connecting Pi pin 2 to U4:VIN and J2 power pins

Tasks not done

Integration of key modules:
- W5500 Ethernet controller footprint
- Seeed Studio XIAO ESP32 socket footprint
- Wi-Fi HaLow (FGH100M-H) module footprint
- Ground portal symbol
Net connections for 3.3 V distribution, MOSI/MISO/SCK, CS/INT/RESET signals
PCB outline definition for 80 mm×60 mm

Unable to do

RF keep-out zone around HaLow module (5 mm clearance)
Position RJ45 MagJack at board edge and allocate module areas
Configure layer stackup, power planes, and ground fill

Success criteria review

Key components added and interconnected: ❌ not yet (W5500, ESP32, HaLow missing)
Power supply distribution: ❌ partial (5 V net done, 3.3 V net not routed)
SPI bus and control signals: ❌ not implemented
RF keep-outs and layout constraints: ❌ not defined

Next step Add the W5500 Ethernet controller, ESP32 XIAO, and Wi-Fi HaLow module footprints (with ground portal), then route the 3.3 V and SPI/control nets to these modules.
