RVT1C102M1010 1000UF 16V

RVT1C102M1010 1000UF 16V thumbnail
Aluminum Electrolytic Capacitors - SMD RVT1C102M1010 1000UF 16V CAP-SMD_BD10.0-L10.3-W10.3-FD LCSC Part Number: C970714 JLCPCB Part Class: undefined Manufactured by DMBJ(振宝佳)

Properties

DMBJ(振宝佳)

C

RVT1C102M1010 1000UF 16V

C970714

CAP-SMD_BD10.0-L10.3-W10.3-FD

Aluminum Electrolytic Capacitors - SMD

1000u

F

Pricing & Availability

DPN

Stock

Qty 1

1

16K

$0.1364
