The Texas Instruments DAC3484 is a highly integrated, low-power, quad-channel, 16-bit digital-to-analog converter (DAC) capable of sample rates up to 1.25 GSPS. This component is designed to simplify complex transmit architectures in telecommunications and broadcast systems, offering features such as 2x to 16x digital interpolation filters with more than 90 dB of stop-band attenuation, which eases data interface and reconstruction filter design. Additionally, the DAC3484 includes independent complex mixers with fine and coarse mixing options for flexible carrier placement, a low jitter clock multiplying phase-locked loop (PLL) for simplified clocking, and digital Quadrature Modulator Correction (QMC) for IQ compensation in direct up-conversion applications. The 16-bit LVDS data bus, equipped with on-chip termination, a FIFO, data pattern checker, and parity test, along with multiple device synchronization capability, addresses the needs for high speed and precision in applications such as cellular base stations, diversity transmitters, and wideband communications. Offering options for very low power consumption and available in both 88-pin WQFN and 196-ball NFBGA packaging options, the DAC3484 is characterized for operation across the industrial temperature range of -40℃ to 85°C, making it a versatile choice for systems designers requiring high performance, multi-channel DAC solutions.
... show more
