STM32F103C8T6 ile fan aç/kapat projesini hazırladım.

STM32F103C8T6 geliştirme kartı eklenecek
Fan için MOSFET sürme katı kurulacak
Güç girişi, koruma ve programlama bağlantıları eklenecek
Tüm bağlantılar tamamlanıp şema kontrol edilecek

Başlatmak için plan çubuğundaki Start düğmesine tıkla.

Plan

#Goal

Design a simple fan on/off controller using an STM32F103C8T6 development board to drive a fan via a MOSFET, including proper power input, protection elements, and maintained programming/debug access.

#Implementation plan

Define system architecture and requirements
1. Specify fan operating voltage/current and identify external power source parameters.
2. Establish grounding strategy and signal interfacing between the STM32 board and the MOSFET drive stage.
Develop the power and switching schematic
1. Add an external power connector and necessary regulation components if required.
2. Implement the MOSFET driver path by connecting an STM32 GPIO to the MOSFET gate with the proper gate resistor and pull-down resistor.
Integrate protection components
1. Add a flyback diode to protect the MOSFET from inductive kickback from the fan.
2. Include input polarity and overcurrent protection where necessary.
Retain programming and debug access
1. Maintain or expose SWD/UART/programming headers.
2. Design the layout to isolate sensitive programming/debug signals from the fan power path.
Validate design for readiness
1. Review component ratings, PCB layout considerations (e.g., proper current handling, thermal margins), and ensure that all sub-systems meet the required specifications.

#Success criteria

The schematic correctly integrates power input, MOSFET driver, protection, and programming/debug access without interference among functionalities.
All components are appropriately rated and connected to achieve a reliable on/off fan control using the STM32F103C8T6 board.
