Carrier Board Design Inquiry

loxi9

change the battery to a cr2350

Thought for 57 sec

flux

You want the carrier board updated to use a CR2350 battery holder instead of a CR2050 battery holder.

I updated the plan to swap the battery requirement to CR2350
The rest stays the same: DRV5032 on GPIO1.11, SWD test pads, and battery-net wiring
Since this source project is read-only, run it in a new editable project

Click Start on the plan bar to proceed.

loxi9

change the battery to a cr2450

Thought for 52 sec

flux

You want the carrier board updated to use a CR2450 battery holder instead of the earlier battery size.

I updated the plan to use a bottom-side CR2450 battery holder
The rest remains: XIAO nRF54L module, DRV5032 on GPIO1.11, and test pads for SWDCK/SWDIO

Click Start on the plan bar to proceed.

Find CR2450 holders

Check holder footprint

Review voltage impact
