General

Project

Model

Do you want me to create the schematic inside your Flux project, or just describe the schematic in detail here? If you want it created, tell me key requirements so I can plan it properly:

Which XIAO variant (e.g., ESP32C3, ESP32S3, RP2040)?
LED types you must support (5V WS2812/WS2813, 12V WS2815), and how many channels/ports?
Power input options (USB-C only, external DC jack/terminal, both) and max current?
Protection/features: level shifting, fuse, TVS, reverse polarity, buck regulator, on/off switch, current sensing?
Optional: UART header, boot buttons, status LEDs, I2C expansion.

105 days

koryfargo

create in new project for me. ESP32C6. 24v FCOB RGBWCCT.

105 days

flux

0:38

General

Chat History

Project

Plan

Model

Got it — I’ll create a new ESP32‑C6 RGBW+CCT (6‑channel) 24V LED driver project and schematic.

Plan summary:

New project with ESP32‑C6, 24V input, RGBW+CCT strip connectors.
Add protections, DC‑DC for 5V/3.3V, and decoupling.
Six MOSFET channels with proper gate drive and PWM mapping.
Boot/program header, pull‑ups, filters; wire all nets.
Run checks and note layout/thermal guidance.

Before I start, quick confirms:

Target current per channel (e.g., 3 A, 5 A)?
Preferred strip interface: one 8‑pin output (24V, GND, R,G,B,W,CW,WW) or multiple connectors?
Any must‑have protections: e-fuse, reverse polarity via ideal diode, TVS at input/outputs?

Click Start on the plan bar and I’ll proceed.

Specify LED current

Define connector style

Set protection requirements

Constrain module choice

Ask about MOSFET topology

105 days

Ready to start.

Show Plan

D10

GND

3V3

+12V

12V

GND

D10

GND

3V3
