Here are the top matches for “ESP32 WROOM”:

Table

Part Name	Manufacturer	MPN	Package	Key Features	Datasheet	Link
ESP32-WROOM-32E-N8	Espressif Systems	ESP32-WROOM-32E-N8	Surface Mount	Wi-Fi 802.11b/g/n, Bluetooth v4.2 + EDR, PCB trace antenna	PDF	ESP32-WROOM-32E-N8
ESP32-WROOM-32E-N4	Espressif Systems	ESP32-WROOM-32E-N4	Surface Mount	Wi-Fi 802.11b/g/n, Bluetooth v4.2 + EDR, integrated PCB antenna	PDF	ESP32-WROOM-32E-N4
ESP32-WROOM-32UE (U.FL antenna connector)	Espressif Systems	ESP32-WROOM-32UE-N16	Surface Mount	Wi-Fi 802.11b/g/n, Bluetooth v4.2 + EDR, supports external U.FL antenna	PDF	ESP32-WROOM-32UE

Recommendation:

If you need the most common ESP32 module with onboard PCB antenna, use the ESP32-WROOM-32E-N8.
For designs that require a smaller antenna footprint, choose the ESP32-WROOM-32E-N4.
If you prefer an external antenna via U.FL, pick the ESP32-WROOM-32UE.

Let me know which one you’d like to add as [IC1], and I can place it for you.

Use ESP32-WROOM-32E-N8

Use ESP32-WROOM-32E-N4

Use ESP32-WROOM-32UE

Ask U.FL footprint
