1. Create a New Project: Begin by creating a new project in Flux. This establishes a workspace for your schematic and PCB design.
2. Design the Schematic: Utilize the schematic editor to draw your circuit. You can add components from the Flux library and wire them together according to your circuit requirements.
   • To place components, simply drag them from the library onto the canvas.
   • Connect the components by drawing wires between appropriate pins.
3. Design the PCB: Once your schematic is complete, you can switch to the PCB layout editor. Flux will automatically generate a PCB layout based on your schematic.
   • You can place components on the PCB, route traces between the component pads, and adjust the layout as needed.
   • Pay attention to the design rules for your PCB, including trace widths, spacing, and the physical dimensions of your board.
4. Verify and Export: Use the design rule checker (DRC) to verify your design for common errors. Once you're satisfied with both your schematic and PCB layout, you can export your design files for manufacturing.

copilot

1. Starting Your Project: When you first log into Flux, you'll want to start a new project. This gives you a clean slate to begin designing your electronic schematic or PCB layout.
2. Creating a Schematic: Before laying out your PCB, you typically start with a schematic. This is where you'll place and connect your components to outline the electrical functionality of your design.
   • Choose the schematic editor from the workspace options.
   • Use the component library to find and place the components you need.
   • Connect the components using the wire tool, making sure to create logical connections that represent your circuit.
3. Designing the PCB: Once your schematic is complete, you can transfer your design to the PCB layout editor.
   • Define your board shape and size.
   • Place the components on the board. Pay attention to placement that minimizes the length of critical signals and avoids any potential interference issues.
   • Route the connections between components, either automatically with the autorouter (if available) or manually for greater control.
4. Review and Export: After completing your PCB design, you'll want to review everything carefully.
   • Check for any errors or unconnected nets.
   • Utilize the design rule check (DRC) to ensure your design meets the necessary specifications for manufacturing.
   • Once satisfied, you can export your design files for manufacturing. This typically includes Gerber files and a bill of materials (BOM).
5. Learning and Support: If you're ever unsure about how to do something in Flux or you encounter issues, there are multiple resources available:
   • Help and Tutorials: Access in-depth tutorials and the first project guide right within Flux[1].
   • YouTube: Watch tutorial videos and example projects[2].
   • Slack Community: Join to ask questions and meet other Flux users[3].
   • Live Support: For direct assistance or more immediate help needs[2].
