@help How do I tell what object type I selected in the PCB editor when Delete is disabled?
56 days
0:59
Chat History
Project
Help
Trace
Addressing user inquiry.
Clarifying tool usage.
Formatting help queries.
Reading docs about How do I tell what object type I selected in the PCB editor when Delete is disabled? Where in the Flux UI can I see the object type and properties of the current selection, and why would Delete be greyed out for some selections?.
Executing help query.
Quoting relevant documentation.
This is the most relevant entry I found related to the topic:
“The Object Tree
The Object Tree contains a structured map of all the elements present in the PCB editor, from parts to nets to traces. This hierarchical view helps you navigate and manage complex designs efficiently.
Inspector
The Layout Inspector panel on the right side shows contextual information about the selected object. When nothing is selected, the inspector shows document-level information like the description, layout rules, and other properties. When a part is selected, it shows contextual information about it.
The Layout Inspector includes several important sections:
Properties: Carry additional part metadata like Manufacturer part number, value, etc.
Pricing and Availability: Flux automatically searches for pricing and availability in parts with an MPN.
Layout Rules: Contains Object-Specific PCB Rules. If you're not sure what the difference is between selector-based and object-specific layout rules, please refer to this guide.
Assets: Leverage existing files (STEP, SVG, etc.) to use as footprints, pad, silk, or board shapes inside Flux designs.”
Source
Use Inspector panel
Check Object Tree selection
Understand Delete disabled
Find selected object ID
