Pumpkin Light Automation Project

flux

0:00

Autopilot
Work completed
  • Footprints assigned for U1 (MAX712CSE), U2 (ATTINY13A-SSU), Q1 (DMN3033LDM), all 8 HSMA-C190 LEDs, their resistors, BAT1 holder, J1 solar connector, SW1, SW2, LDR07, and D1 blocking diode.
  • LED_ARRAY nets formed: each LED anode → series resistor → LED_ARRAY net.
  • Power nets (VIN, BATT+, SOLAR_PANEL_POS) connected per topology.
  • Group properties set: LEDs+Q1 under LED_Driver, U2+SW1+SW2 under Control_UI.
  • Board outline set to 1021.0 mm × 879.1 mm; four M3 non-plated mounting holes placed at corners.
  • PCB layout settings updated: 0.25 mm for LED_ARRAY, 0.5 mm for Power_Nets.
  • Footprint placements verified against schematic.
Tasks remaining
  • Review and confirm net connections and component groupings on the PCB layout.
  • Execute Auto-Place and Auto-Route, then perform ERC/DRC checks.
Cannot do
  • Automated review of PCB grouping and net connections.
  • Running Auto-Place/Auto-Route and performing ERC/DRC checks.
Success criteria status
  • ✅ All key footprints assigned correctly
  • ✅ Net connections and trace widths configured
  • ✅ Component groups labeled
  • ✅ Board outline and mounting holes defined
  • ❌ Auto-Placement & Auto-Routing with ERC/DRC not yet completed
Next step Would you like me to proceed with Auto-Placement and Auto-Routing on the PCB layout, or shall I review the layout grouping and nets manually before routing?
