Magnetic Encoder utilizing hall effect sensor for N20 gear motors.

QFN50P250X250X100-12N Texas Instruments IC REG BCK BST 3.3V 0.5A HOTROD VQFN-12 Texas Instruments 1.25 USD TPS63051RMWR Good

A class of rotary electrical motors that converts direct current (DC) electrical energy into mechanical energy.

CONN6x1_BM06B-SURS-TF_JST ~

The DRV5013 from Texas Instruments is a chopper-stabilized Hall Effect sensor designed for digital bipolar latch output applications, renowned for its superior sensitivity stability across a wide range of temperatures. This component is equipped with multiple sensitivity options, ranging from +1.3 mT (FA version) to +12 mT (BC version), catering to a breadth of magnetic sensing needs. With an operating voltage range of 2.5 V to 38 V and built-in reverse supply protection up to -22 V, as well as load dump and short-circuit protection, the DRV5013 ensures reliability and robustness in demanding environments. The device comes packaged in small form factors, including a 3-pin SOT-23 and 3-pin TO-92, facilitating integration into a variety of industrial applications such as power tools, flow meters, and brushless DC motors. Temperature stability is guaranteed with operating ranges from -40°C to +125°C (Q version) and -40°C to +150°C (E version), making the DRV5013 an ideal choice for applications requiring precise and dependable magnetic field detection across a wide environmental range.

USON-8_UX_2x3x0p6_WIN ~
