RPI or PC
You need a high gain wifi parabolic or grid antenna to receive the satellite dat...
jharwinbarrozo

jharwinbarrozo

You need a high gain wifi parabolic or grid antenna to receive the satellite data. Click on the antenna symbol, and look at the right panel's properties to see where you can source/buy one.

1

5y
Someone is typing...
2
We will use software defined radio/receiver (SDR device) to convert the received...
jharwinbarrozo

jharwinbarrozo



https://uploads-ssl.webflow.com/5f1af4c2e67caae8e13187f1/6009e3c3630bde30ef2203a0_IMG_FD_001_IR105_20210119_001006.jpg
5y
5y
lwcassid

lwcassid

Do you have an example of what it was able to process?
5y
jharwinbarrozo

jharwinbarrozo

We will use software defined radio/receiver (SDR device) to convert the received signal so that a computer or rpi can process it.

2

5y
Someone is typing...
4
If you're located in the US, there's GOES satellite. If you're in Asia or Austra...
jharwinbarrozo

jharwinbarrozo

If you're located in the US, there's GOES satellite. If you're in Asia or Australia, there's GK-2A (Geokompsat 2A). These are geostationary satellite so they always stay at a fixed point in the sky. You need https://www.dishpointer.com/ in order to know exactly where to point your antenna from your location.

3

5y
Someone is typing...
2
Click on the block below to see all the needed softwares to decode and process t...
jharwinbarrozo

jharwinbarrozo

Click on the block below to see all the needed softwares to decode and process the satellite data.

1

5y
Someone is typing...
5
The satellite signal is very weak so the first stage here is to increase the rec...
jharwinbarrozo

jharwinbarrozo

But an ordinary wideband low noise amplier has proven to work also.

1

5y
jharwinbarrozo

jharwinbarrozo

The satellite signal is very weak so the first stage here is to increase the received signal thus a (LNA) low noise amplifier is really needed. Nooelec offers a LNA that comes with built in SAW filter, it only amplifies the signal at a designed frequency section.

1

5y
Someone is typing...
6
This is one my decoded raw image.
jharwinbarrozo

jharwinbarrozo



https://uploads-ssl.webflow.com/5f1af4c2e67caae8e13187f1/6009e3c3630bde30ef2203a0_IMG_FD_001_IR105_20210119_001006.jpg
5y
jharwinbarrozo

jharwinbarrozo

This is one my decoded raw image.
5y
Someone is typing...
8
Software Defined Receiver (SDR)
ANTENNA
Low Noise Amplifier (LNA)

No results...

Learn to Add a Component

GK2A or GOES satellite setup to decode

GK2A or GOES satellite setup to decode thumbnail
The main hardware components which make up a GK-2A or GOES receiver are a parabolic dish antenna with reasonable gain at 1.7 GHz, a low-noise amplifier and a software defined radio (SDR). The Airspy Mini, Airspy R2 and RTL-SDR (also available at NooElec) are all compatible with GK-2A or GOES receiver software. NooElec offers an excellent low-noise amplifier solution which also includes a SAW filter centered on 1688 MHz.
