R2 w Thread changes:
-Moving to Letter Modules for ease of design
-Adding MGM210L for Matter on Thread On/Off and intensity control
-Shifted A and R letters closer to fix Kerning
-Optional: Add unpopulated AA Battery Holder for battery option
R1 changes:
-Changed LED part to Red LEDs
-adjusted resistor value of buck converter
-Changed source for USB-C Connector
-Removed exposed soldermask on buck converter with negative soldermask expansion
-Order with black soldermask
Modified by markwu2001:
- Adjustable Brightness,
- 85-90% Drive Efficiency
- <5W Operation (Can use 5V 1A Plug)
This project can be purchased from LCSC
Original Description:
Daddy's second circuit board. A sign to let my wife know when I'm on a call. Activates with a slide switch and is powered by USB-C.
#template #arduino-matter
... show more
Template for Raspberry Pi 4 Shield. Include an official pinout so you will always know Raspberry Pi names, the alternative roles of pins, which one is SDA, or SCL, etc. On PCB you can find the 3D model of the Raspberry Pi itself along with the board outline on the silkscreen.
#RaspberryPi #Raspberry #Pi #RPi #Shield #template #project #project-template #raspberry
... show more1 Comment
Change History from V1:
-13.56MHz tuning
-larger instruction font
-put some stuff on the back
#template
I wanted to create a business card that has some functionality and shows off a bit of my portfolio IRL:
-NFC to my flux page -here's the [instructables](https://www.instructables.com/PCB-Business-Card-With-NFC-Make-Yours-With-NFC-QR-/)
-Put a bunch of modules on it
Find the BoM [here](https://www.digikey.com/short/2db2vnmp)
... show more
