The digital 18 bit board-mount pressure sensors in the AMS 5935 series are designed for high precision pressure measurements. They combine very high measurement accuracy with extremely low power consumption. The AMS 5935 are housed in a robust ceramic DIL-8 package for PCB assembly. They have an integrated I2C / SPI interface, which allows the readout of calibrated pressure and temperature data. They are extensively calibrated and temperature compensated and feature an extremely low measurement error at room temperature as well as a very small total error band in the compensated temperature range of -25 ... 85 °C. With a supply voltage range of 1.7 V up to 3.6 V and the extremely low current consumption in sleep mode, the AMS 5935 pressure sensors are especially suitable for battery powered microcontroller applications.

AMS 5812 is a series of high precision pressure sensors combining a ratiometric analog voltage output with a digital I2C output. They are calibrated and compensated in a temperature range of -25 ... 85 °C. The PCB- mountable sensors are available in a ceramic DIP package in variants with tube fittings or for o-ring sealing. Datasheet Pressure Sensor AMS5812: https://www.analog-micro.com/products/pressure-sensors/board-mount-pressure-sensors/ams5812/

AMS 6915 is a series of board mountable digital pressure sensors in a compact DIL package with horizontal or vertical tube fittings. The calibrated and temperature compensated sensors with I2C-interface have an operating temperature range of -25 ... 85 °C and are especially suitable for microcontroller applications. Ultra low pressure variants are available for differential pressure measurements down to ±2.5 mbar.

The pressure sensors in the AMS 5915 series are high-precision board mount sensors with a digital I²C-interface. They combine a micromachined, high quality piezoresistive pressure sensing element with a modern, mixed-signal CMOS-ASIC used for signal conditioning on a ceramic substrate. AMS 5915 sensors are extensively calibrated and compensated across a wide temperature range of -25 to 85 °C
