I’ll fork/create an editable project for the microphone splitter, then add a custom AT2510P component plan with the confirmed pinout and Neutrik connector choices.

flux

Fork created: /jack635/4-channel-microphone-splitter-at2510p. I started a focused task inside it to create the custom AT2510P transformer component/footprint with the confirmed pinout and datasheet dimensions.

flux

I forked the template into your editable project: /jack635/4-channel-microphone-splitter-at2510p
I also launched and completed a focused task to create the custom SHINHOM AT2510P transformer component/footprint using your confirmed pinout and datasheet dimensions.
Open items:
  • Verify the new AT2510P symbol/footprint in the forked project.
  • Add the 4 replicated splitter channels.
  • Add Neutrik XLRs, 3 HE10 headers, 51 Ω / 10 nF ground-lift networks, and channel labels.
  • Run schematic review, then proceed to PCB placement/layout.
Execution is now blocked because your account has no available ACUs, so AI features can’t continue modifying the project until ACUs are available.
Manual channel steps
Find Neutrik connectors
Check footprint dimensions
Run ERC/DRC
Document pinout
